HP rp7420

Figure 5-8 Core I/O Card Bulkhead LEDs
Table 5-7 Core I/O LEDs
DescriptionStateLED (as silk-screened on the
bulkhead)
I/O power onOn GreenPower
PCI attentionOn YellowAttention
Core I/O is managing the systemOn GreenMP Master
Core I/O is managing the DVD/TapeOn GreenDVD/Tape
Failure during POSTOn YellowSelf-Test
MP LAN activityOn GreenMP LAN Act
MP LAN in 10 BT modeOn GreenMP LAN 10 BT
MP LAN in 100 BT modeOn GreenMP LAN 100 BT
LED Indicators 75
