Figure 2-8 Raising a Server Off the Pallet
7. Roll the lifter and server away from the pallet. Do not raise the server any higher than
necessary when moving it over to the rack.
NOTE: When installing the system in a rack, use the HP J1530B Rack Integration Kit Installation
Guide.
Unloading the Server With Lift Handle Panels
WARNING! Use this procedure only if an HP approved lift is not available. This procedure
should only be attempted by two authorized HP service technicians.
Before attempting this procedure, HP recommends that you remove all cell boards and AC power
supplies. Instructions for removing these components can be found in the Chapter 6 (page 83).
Review local safety regulations before attempting to move the system, using the lift handle
panels.
Failure to observe these precautions can cause serious injury to personnel or damage to equipment.
CAUTION: Unpack the server in an ESD safe environment. Observe all ESD safety precautions
before attempting this procedure. Failure to follow ESD safety precautions could result in damage
to the server.
To install the lift panels, follow these steps:
1. Remove both side covers. If present, remove the front panel.
2. Locate lift handles and remove from storage plate.
3. Orient lift handle panels such that when installed, the handles hang down at 90 degrees and
lock in a horizontal position during lifting.
Unpacking a Non-Racked Server 37
