HP rp7420 Service Manual

Table 5-8 Core I/O Buttons
FunctionLocationButton Identification (as
silk-screened on the
bulkhead)
Resets the MP
NOTE: If the MP RESET button is held for longer than five
seconds, it clears the MP password and reset the LAN, RS-232
(serial port), and modem port parameters to their default
values.
LAN Default Parameters
• IP Address—192.168.1.1
• Subnet mask—255.255.255.0
• Default gateway—192.168.1.1
• Hostname—gsp0
RS-232 (Serial Port) Default Parameters
• 9600 baud
• 8 bits
• No parity
Remote/Modem Port Parameters
• Disabled
Center of the core I/O cardMP RESET
Request OL* for this core I/O slot
NOTE: The OLR function is not enabled for the core I/O card.
Top end of the core I/O cardOLR (Symbol next to
button is shown below)
PCI-X Hot-Plug LED OL* LEDs
Table 5-9 OL* LED States
Attention (Yellow)Power (Green)State
OffOnNormal operation, slot power on
FlashingOnSlot selected, slot power on
OnOnSlot needs attention, slot power on
OffOffSlot available, slot power off
FlashingOffReady for OL*, slot power off
OnOffFault detected, slot power off
OffFlashingSlot powering off or on
Disk Drive LEDs
There are two tri-color LED on each disk drive.
LED Indicators 77
