HP StorageWorks 6400/8400 - Enterprise Virtual Array - 3-Site Configuration with Six MPX200 Routers and Full Inter-Site Connectivity; HP Continuous Access EVA 3 Site Configuration with Eight MPX200 Routers

Figure 81 HP Continuous Access EVA 3–site configuration with eight MPX200 routers
.
3-site configuration with six MPX200 routers and full inter-site connectivity
Figure 82 provides long-distance link redundancy and full connectivity between all three sites.
MPX200 FCIP124
