Yes88M50
No74M25
No74M20
No62M15
No62M10
No51M5
No4512K2.5
No2128K1 or less
Configuring an FCIP route
Step 1. Verify your system requirements
Verify that you have the following for both the local site and the remote site (see Figure 65 on page 113):
• HP StorageWorks MPX200 Multifunction Router 1–GbE Base Chassis or HP StorageWorks MPX200
Multifunction Router 10–1 GbE Base Chassis. Note that FCIP is currently supported only on MPX200
1 GbE ports.
• HP Storage Works MPX200 Half Chassis FCIP License
• Continuous Access EVA
• EVA3000/5000 or EVA4x00/6x00/8x00 storage system
• FC fabrics consisting of B-series or C-series switches
• Cat 5e network cable, three per site (mgmt, (2) FCIP)
• Optical small form-factor pluggable (SFP) transceiver and FC cable, two per site
• MPX200 serial console cable adapter, Cat 5e network cable
Additional equipment for the local site and remote site (see Figure 71 on page 118 and Figure
73, page 118) is as follows:
• HP StorageWorks MPX200 Multifunction Router 1–GbE Upgrade Blade (MPX200 blade for re-
dundancy)
• Or HP StorageWorks MPX200 Multifunction Router 10–1 GbE Upgrade Blade. Note that FCIP
is currently supported only on MPX200 1 GbE ports.
• HP Storage Works MPX200 Full Chassis FCIP License
NOTE:
For the latest information about operating system and multipath software support, see SPOCK at the
website http://www.hp.com/storage/spock. You must sign up for an HP Passport to enable access.
Step 2. Pre-installation checklist
Before you begin the configuration process, contact your system administrator for the following
information for both sites:
MPX200 Multifunction Router 133
