5. From the list box, select Windows as the host mode value, as shown in Figure 130.
Figure 130 Selecting the host mode
.
6. Select the LUNs to be assigned to the DM-Host by checking the box associated with the previously
planned LUNs, as shown in Figure 131.
Figure 131 Selecting LUNs
.
7. To accept and save the LUN assignment, click OK.
8. Refresh the data migration user interface to see if the LUN assignment is reflected properly and
that the appropriate array entity appears under FC Array. (You may need to click the Refresh
button several times to correctly reflect the changes.)
Assigning LUNs from an HDS array
HDSStorage Vendor
AMS/WMS series arraysArray Model
Storage Navigator Modular user interfaceLUN Assignment Tool
To assign LUNs:
Data migration best practices384
