14. Complete the Modify Mapping dialog box as follows (see Figure 136):
a. Under H-LUN / Available Logical Units, select an appropriate LUN.
b.
Click the (up arrow) to map the LUN to the DM-Host group.
c. To accept and save the LUN assignment, click OK.
Figure 136 Modifying mapping
.
15. Refresh the data migration user interface to see if the LUN assignment is reflected properly and
that the appropriate array entity appears under FC Array. You may have to reboot the data
migration appliance or generate a registered state change notification (RSCN) to initiate a full
rescan on HDS array, because it does not send any notification indicating changes in LUN
assignment to the logged in initiators.
Assigning LUNs from an IBM DS4K/DS5K/LSI array
IBMStorage Vendor
IBM DS4000/Engineo series arraysArray Model
Storage Manager Client 1eLUN Assignment Tool
To assign LUNs:
MPX200 Multifunction Router 389
