Item LED Status Definition
O Removing the drive does not cause a logical drive to fail.
4 Drive
status
Solid green The drive is a member of one or more logical drives.
Flashing green
The drive is doing one of the following:
• Rebuilding
• Performing a RAID migration
• Performing a strip size migration
• Performing a capacity expansion
• Performing a logical drive extension
• Erasing
• Spare part activation
Flashing amber/
green
The drive is a member of one or more logical drives and predicts the drive will fail.
Flashing amber The drive is not configured and predicts the drive will fail.
Solid amber The drive has failed.
O The drive is not configured by a RAID controller or a spare drive.
Drive bay numbering
CAUTION: When a server is purchased without any drive installed, some drive bays might be empty while other
drive bays might be populated with drive blanks.
To maintain proper system cooling, do not operate the server without a drive or a drive blank installed.
Drive bay numbering depends on how the drive backplane is connected. In this server, the backplane can be connected to
the:
• Embedded Smart Array controller through the onboard SATA ports
• Smart Array type-p SR Gen10 controllers
• SAS expander card
When the backplane is connected to a storage controller, the drive bay numbering for each drive box starts at 1.
When the backplane is connected to a SAS expander, all drive boxes are treated as a single box 1. This means the drive
bay numbering is continuous.
• LFF drive bay numbering: Smart Array controller
Component identification
109
