HPE ProLiant ML110 Gen10

6. Remove the PCI air bale.
7. Remove the system air bale.
8. Remove the DIMM.
To replace the component, reverse the removal procedure.
Removing and replacing the optical drive
Procedure
1.
Power down the server.
2.
Remove all power:
a.
Disconnect each power cord from the power source.
b.
Disconnect each power cord from the server.
3.
Disconnect all peripheral cables from the server.
4.
Do one of the following:
• Server in rack mode:
Remove the server from the rack.
• Server in tower mode: Position the tower server for hardware configuration.
5.
Remove the access panel.
6. Remove the system air bale.
7. Remove the PCI air bale.
8. Disconnect all cables from the optical drive, and then remove the cables from the clip and metal tabs.
9. Press the metal tab to remove the optical drive.
Removal and replacement procedures
52
