7. Remove the system air bale.
8. Disconnect all SAS expander card cables from the storage controller.
9. Remove the SAS expander card:
a. Open the PCI slot retainer.
b.
Remove the SAS expander card.
10. Disconnect all cables from the SAS expander card.
11. If you do not intend to replace the SAS expander card, install the PCI slot retainer.
Removal and replacement procedures
68
