ItemItem DescriptionDescription
1 NS204i-u device slot 1 (optional)
2 NS204i-u device slot 2 (optional)
3 Flexible Slot power supply 1
4 Slots 9–10 PCIe5 x8 (tertiary riser)
5 Flexible Slot power supply 2 (optional)
6 VGA port
7 Slot 15 OCP PCIe5 x16
8 Serial port (optional)
9 iLO management port
10 USB 3.2 Gen 1 ports (2)
11 Slot 14 OCP PCIe5 x16
12 Slots 1–4 PCIe5 (primary riser)
13 Padlock eye
14 Slots 5–8 PCIe5 (secondary riser)
15 Kensington slot
Two processors are required for installing the secondary riser option. The same is required for a tertiary riser option used for NIC
