FULLTEST3
EN - 36
8. Save the test result by pressing the SAVE key (see § 7.1)
CAUTION
x Max external voltage between two RPE or between two SENSE
test terminals is 10 VAC, no DC external voltage is allowed! In
case of higher external voltage fuse F4 (T20A/500V, 6.3×32 mm)
may blow
x If SENSE test leads are not connected, then measurement result
will include also the resistance of current test leads
x Measurement time in MANUAL mode is limited to 5min
6.2.2. Anomalous situations
The following specific information can be shown on the display during measurement
Information displayed Description
EXTERNAL VOLTAGE
x External voltage higher than 3 V AC is applied
between two R
PE or between two SENSE test
terminals (measurement is not running) or
higher than 10 V AC (measurement is
running).
x External voltage higher than 5 y30 V is applied
between any R
PE or SENSE test terminal and
GND.
Remove external voltage!
FUSE F4!
Fuse F4 is blown.
ERROR1!
Internal fuse may be blown!
The fuse is not customer replaceable, send the
tester into a service department.
MEAS. TIME > 5MIN
CHECK TIMER
The Timer is set to a value higher then 5
minutes with 25A test selected.
The test with 25A current allows to set the timer
up to maximum 5 minutes
