FULLTEST3
EN - 76
Meaning of symbols on the display
Item Description
1 Selected function
2 Sub-result, mains voltage UL/N
3 Measurement screen touch-screen key
4
MODE touch-screen key to select measurement mode (SOCKET)
Currently selected mode is displayed on the bottom of the key
5
LIMIT touch-screen key to select limit leakage current. Currently selected
value is displayed on the bottom of the key
6
L POS touch-screen key to select the position of phase terminal on
schuko socket during the measurement. Currently selected position is
displayed on the bottom of the key
7
Measurement result (in green colour - result OK, in red colour - result not
OK).
8 Real time clock (hh.mm.ss)
9 Unit of the test result
10
Measurement result status (symbol
in green colour - result OK,
symbol
in red colour - result not OK).
9. Save the test result by pressing the SAVE key (see § 7.1)
CAUTION
x Measurement at both phase positions (phase at left terminal and
phase at right terminal) must be carried out and the highest
value must be evaluated
x Switch on the UUT in order total leakage current to be measured
x In case of overloaded test socket the fuse F1 or F2 (both
T16A/250V) may blow
x Do not use test schuko socket except for measurement purpose
x Measurement time (SOCKET) is limited to 60 min
6.12.1. Anomalous situations
The following specific information can be shown on the display during measurement
Information displayed Description
IPE CURRENT OVERRANGE!
If I
PE current is higher than 10A for 10s, the
measurement will be stopped and this message
will appear
