FULLTEST3
EN - 70
Meaning of symbols on the display
Item Description
1 Selected function
2
Measurement sub-results as follows: Phase-to-phase voltage U
L1/2,
phase-to-phase voltage U
L2/3 and phase-to-phase voltage UL3/1
3 Measurement screen touch-screen key
4
Measurement result (in green colour - result OK, in red colour - result
not OK
5 Real time clock (hh.mm.ss).
4. Save the test result by pressing the SAVE key (see § 7.1)
6.10.1. Anomalous situations
The following specific information can be shown on the display during measurement
Information displayed Description
VOLTAGE OUT OF RANGE
One of more input phase-phase voltages is out
of required range 100V y 460V
1.1.X
At least one of measured phases was
disconnected during the measurement.
Connect all three phases and repeat the
measurement.
