FULLTEST3
EN - 88
TECHNICAL SPECIFICATIONS
10.5. TECHNICAL CHARACTERISTICS
Accuracy calculated as ±[%reading + (num.dgt * resolution)] at 23°C ± 5°C, <60%RH
CONTINUITY OF PE CONDUCTOR (RPE-2WIRE, 200mA)
Range [
] Resolution [
]
Accuracy
Overload
protection
0.00 y 19.99
0.01
± (3%rdg + 3dgt) CAT III 300 V
20.0 y 200.0
0.1
Open-circuit test voltage: approx. 4.5VAC
Short-circuit test current: <0.6A (standard test leads)
Test current: >200mA (standard test leads and external resistance < 20:)
Range of test current: 10mA y 255mA
Accuracy of test current: ±(3%rdg. + 2dgt)
Limit value: 0.01: y 200.0: adjustable
Timer on measurement: 2s ÷ 60min programmable
Measurement principle: 2-Wire connection
Test lead calibration: up to 5.00:
Protection: Fuse F4
Detection of external voltage UEXT lim = 3VAC (between two RPE or between two SENSE terminals
UEXT lim = 10VAC (between two RPE or between two SENSE terminals
UEXT lim = 30VAC approx. (between any RPE/SENSE terminal and GND
CONTINUITY OF PE CONDUCTOR (RPE-2WIRE, 25A)
Range [
] Resolution [
]
Accuracy
Overload
protection
0.000 y 1.999
0.001
± (3%rdg. + 3dgt) CAT III 300 V
2.00 y 20.00
0.01
Open-circuit test voltage: approx. 4.5VAC
Short-circuit test current: <30A (standard test leads)
Test current (25A range): > 25A (standard test leads and external resistance < 0.1
)
>10A (standard test leads and external resistance < 0.5
)
Range of test current: 0.2A y 30.0A
Accuracy of test current: ± (3%rdg. + 1dgt)
Limit value: 0.01: y 20.00: adjustable OR calculation through loop impedance OR
calculation through wire length
Timer on measurement: 2s ÷ 60min programmable (test current > 10A)
2s ÷ 5min programmable (test current > 25A)
Measurement principle: Two-wire connection
Test lead calibration: Up to 5.00 :
Protection: Fuse F4
Detection of external voltage Yes (see RPE-2WIRE, 200mA)
CONTINUITY OF PE CONDUCTOR (RPE-4WIRE, 25A)
Range [
] Resolution [
]
Accuracy
Overload
protection
0.000 y 1.999
0.001
± (3%rdg. + 3dgt) CAT III 300 V
2.00 y 20.00
0.01
Open-circuit test voltage: approx. 4.5VAC
Short-circuit test current: <30A (standard test leads)
Test current (25A range): >25A (standard test leads and external resistance < 0.1
)
>10A (standard test leads and external resistance < 0.5
)
Range of test current: 0.2A y 30.0A
Accuracy of test current: ± (3%rdg. + 1dgt)
Limit value: (see RPE-2WIRE 25A)
Timer on measurement: 2s ÷ 5min programmable
Measurement principle: 4-Wire connection
Protection: Fuse F4
automatically detected
Detection of external voltage Yes (see RPE-2WIRE, 200mA)
