FULLTEST3
EN - 9
x Leakage current
¾ Measurement of I
PE current on schuko socket
(differential method).
¾ Measurement with current clamp type HT96U, three
ranges 1 A, 100 A and 1000 A.
¾ Limit value adjustable, visual and acoustic warning in
case of exceeded value.
x General specifications
¾ Portable Machinery & Panel Tester constructed
according to the IEC/EN60204-1 and IEC/EN61439-1
standards
¾ Operation system WINDOWS EMBEDDED
COMPACT 7 supports all measurements and
operations
¾ Easy and clear operation by using the touch screen
and intuitive hard keys
¾ TRMS measurements
¾ Data memory for 999 measurement results
¾ AUTEOTEST feature
¾ Real time clock included.
¾ Integrated interface (USB 2.0) for transfer of
measurement results to PC
¾ Separate interface (USB 2.0) for connection of USB
barcode reader, USB keyboard, USB memory stick,
printer or IMP57-impedance tester.
¾ Graphic touch screen 102×60 mm, 480×272 dots.
¾ Compact housing with external accessory bag.
¾ Quick connection diagrams and limit values under the
instrument cover
¾ Fuse protection in case of overload
¾ PC Software TOPVIEW available
¾ Complete test accessories included.
¾ Bluetooth communication
¾ Remote START/STOP and SAVE function.
2.2. OPEN INSTRUMENT COVER
The instrument is built in a robust plastic case that allows comfortable transport. We
recommend the user to follow the next opening instructions:
1. Place the unit on to a hard horizontal surface
2. Press on the case cover with your hands, see the mark 1
3. Unlock the fixing hooks of the cover, see the mark 2
4. Open the cover into vertical position
1
2
Fig. 1 : Opening the instrument’s cover
