8.1 Setting PTZ and Serial Port Parameters
You can set parameters for connecting the PTZ to cameras through the serial port, for
example, serial port parameters and transparent channel parameters.
8.1.1 Setting Serial Port Parameters
You can set serial port parameters for the IPC to implement communication with the PTZ.
Prerequisites
The IPC is connected to an external PTZ, and the PTZ has been configured.
Procedure
Step 1 Choose Settings > PTZ Configuration > PTZ&Serial Port Parameters.
The PTZ&Serial Port Parameters page is displayed, as shown in Figure 8-1.
Figure 8-1 PTZ&Serial Port Parameters page
Step 2 Set serial port parameters. For detailed parameter description, see Table 8-1.
Table 8-1 Parameter description
Parameter
Description
No. ID of the serial port.
Baud rate Communication rate, which must be the same as that of the
connected PTZ.
