Table 8-2 Parameter description
Parameter Description
PTZ ID Unique ID of the PTZ.
Enable serial port Indicates whether to enable the serial port.
Serial port ID The same as the PTZ serial port number.
PTZ protocol The same as the PTZ protocol.
PTZ address The same as the PTZ address.
Direction control Enables forward or backward PTZ control:
l Forward
Enables the forward control of the PTZ. For example, if
you click the left button, the PTZ moves leftward.
l Backward
Enables the backward control of the PTZ. For example, if
you click the left button, the PTZ moves rightward.
Wiper linkage switch
output 1
Indicates whether to enable the wiper linkage switch output
1.
NOTE
l To use the rain wiper that is controlled by the Boolean value,
connect the rain wiper to Boolean value output 1 and enable this
function.
l You cannot enable this function if Boolean value output 1
connects to an alarm device.
l If this function is disabled, the rain wiper button is unavailable.
Step 3 Click Save.
----End
8.2 Setting Preset Position Parameters
After a preset position is configured, you can quickly rotate the IPC to the required position.
You can add, modify, and delete preset positions. A maximum of 256 preset positions can be
added for an IPC.
Context
The IPC's horizontal shooting angle, vertical shooting angle, and zoom times can be stored as
a preset position. The preset position can be numbered.
Procedure
Step 1 Choose Settings > PTZ Configuration > Preset Parameters.
The Preset Parameters page is displayed, as shown in Figure 8-4.
