Parameter Description
Data bit Actual number of data bits used for the communication.
Stop bit Number of bits used for marking the end of the serial port data.
Parity check bit Method to check the serial port data.
Step 3 Click Save.
----End
8.1.2 Setting Transparent Channel Parameters
The transparent channel is a data transmission channel provided in the SDK protocol.
Prerequisites
The IPC is connected to an external PTZ, and the PTZ has been configured.
Procedure
Step 1 Choose Settings > PTZ Configuration > PTZ&Serial Port Parameters.
The PTZ&Serial Port Parameters page is displayed, as shown in Figure 8-2.
Figure 8-2 PTZ&Serial Port Parameters page
Step 2 Set transparent channel parameters.
NOTE
The Enable in the transparent channel and Enable serial port in the PTZ parameters area cannot be selected
at the same time.
