Locati
on
Display Name Addr
ess
DIP Switch Sequence No.
1 2 3 4 5 6
Cold
aisle
Cold aisle 1
temp/humid
11 ON ON OFF ON OFF OFF
Cold aisle 2
temp/humid
12 OFF OFF ON ON OFF OFF
Cold aisle 3
temp/humid
13 ON OFF ON ON OFF OFF
Cold aisle 4
temp/humid
14 OFF ON ON ON OFF OFF
Cold aisle 5
temp/humid
15 ON ON ON ON OFF OFF
Hot
aisle
Hot aisle 1
temp/humid
21 ON OFF ON OFF ON OFF
Hot aisle 2
temp/humid
22 OFF ON ON OFF ON OFF
Hot aisle 3
temp/humid
23 ON ON ON OFF ON OFF
Hot aisle 4
temp/humid
24 OFF OFF OFF ON ON OFF
Hot aisle 5
temp/humid
25 ON OFF OFF ON ON OFF
NO TICE
After the addresses are set, power on the device, choose Settings > System
Settings > T/H Sensor on the home screen, and set the sensors in the aisles
corresponding to the addresses to Enable. Otherwise, the sensors will not work.
----End
