Exercise caution because the device is still energized after it is shut down on the
controller home screen.
Step 2 Open the front door, and disconnect the white power cable terminals of the
condensate pump at the lower right corner of the cabinet.
Figure 11-36 Disconnecting the power cable terminals
Step 3 Remove the condensate pump assembly, as shown in Figure 11-37.
Figure 11-37 Removing a condensate pump assembly
1. Remove the hose clamps at the water pan drain outlet and check valve outlet,
and remove the hoses.
NetCol5000-A050 In-row Air Cooled Smart Cooling
Product
User Manual 11 Parts Replacement
Issue 08 (2021-09-17) Copyright © Huawei Technologies Co., Ltd. 280
