Components
Figure 3-80 10-Port-MPO-12-40-Port-LC-Breakout Box(single-mode)
1. MPO adapter 2. LC adapter 3. Mounting ear
MPO adapters map LC adapters according to their numbers displayed on the
panel. Figure 3-81 shows the mapping between MPO and LC adapters.
Figure 3-81 Mapping between MPO and LC adapters
MPO-12 Jumper
The TYPE-B MPO jumper is used. The following
gure shows the MPO-12 jumper
structure and line orders of X1 and X2 ports.
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 343
