The adjustment range of adjusting anchor is from 0 mm to 10 mm.
2. Testing the insulation of the cabinet.
a. Set the multimeter to read mega ohms.
b. Measure the resistance between the expansion bolt and the ground bolt
of the rack, the measured resistance is more than
ve mega ohms.
Figure 4-13 Testing the insulation of the cabinet
If the measured resistance is less than ve mega ohms, check whether any
insulation part is damaged or not installed. Measure the resistance again.
Otherwise, remove all components, install and fasten the cabinet again.
Attaching the cabinets
1. Remove the connection plates on the lintels of the front and rear doors and
install them again as shown in the
gure.
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 360
