The cabinet has the following features and functions:
● Static load bearing capability: 1 ton
● Sucient space to place and connect components.
● Ability in protecting internal components from contamination.
● Ability in preventing damage to internal components.
Physical Structure
Figure 4-187 shows components of the A610 cabinet.
Figure 4-187 Cabinet components
1. Front door 2. Top cover 3. Rear door
4. Side panel 5. Mounting rail 6. Rack
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 525
