Port Connector Type Description Available
Components
20–27 QSFPDD Port for inputting
and outputting
400GE/100GE/
50GE/40GE
optical signals
NOTE
1. Port 20 shares
400G bandwidth
with ports 8, 9,
and 12. Port 21
shares 400G
bandwidth with
ports 10, 11, and
14. Port 22 shares
400G bandwidth
with ports 13, 16,
and 17. Port 23
shares 400G
bandwidth with
ports 15, 18, and
19.
2. Port 24 shares
400G bandwidth
with ports 28 and
29. Port 25 shares
400G bandwidth
with ports 30 and
31. Port 26 shares
400G bandwidth
with ports 32 and
33. Port 27 shares
400G bandwidth
with ports 34 and
35.
3. Ports 20–25
support FlexE.
400Gbps QSFP-
DD Optical
Module
100Gbps QSFP28
Optical Module
50Gbps QSFP28
Optical Module
50Gbps QSFP28
BIDI Optical
Module
40Gbps QSFP+
Optical Module
NOTE
1.Devices that
work in port-side
air exhaust mode
do not support 40
km and 80 km 400
Gbit/s optical
modules.
2.When an 80 km
QSFP-DD optical
module is applied,
the optical
amplier is
required.
28–63
QSFP28 Port for inputting
and outputting
100GE/50GE/
40GE optical
signals.
NOTE
Ports 36-51
support 4*25G and
4*10G breakout
optical module.
100Gbps QSFP28
Optical Module
50Gbps QSFP28
Optical Module
50Gbps QSFP28
BIDI Optical
Module
40Gbps QSFP+
Optical Module
GE0/GE1 SFP Cascading port
used for control
panel expansion
in scenarios like
virtual cluster
(reserved)
Reserved
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 46
