Huawei NetEngine 8000 F

Port Connector Type Description Available
Components
HP-GE SFP High-precision
clock port
(reserved)
Reserved
MGMT-ETH RJ45 Port for
connecting to the
NMS workstation
Category 5
enhanced
shielded twisted
pair
Console/AUX
hybrid
RJ45 Port for
connecting to the
console for onsite
system
conguration. The
default baud rate
is 9600 bit/s. (The
AUX hybrid port is
reserved.)
8-core shielded
cable
TOD clock RJ45 Port for inputting
and outputting
one-channel 1PPS
+TOD time signals
or one-channel
DCLS signals
120-ohm clock
cable
CLK RJ45 Port for inputting
and outputting 2
Mbit/s or 2 MHz
clock signals
120-ohm clock
cable
USB Type A USB port
(reserved)
N/A
Interface Numbering Rules
On the NetEngine 8000 F2A-8K36H, an interface is numbered in the format of
"slot number/subcard number/port number". The following part describes the
details:
● Slot number
The slot number of NetEngine 8000 F2A-8K36H is always 0.
● Subcard number
The NetEngine 8000 F2A-8K36H does not support subcards. Therefore, the
subcard number of the 8000 F2A-8K36H is xed as 1.
● Port number
The port numbers of service interfaces on the NetEngine 8000 F2A-8K36H
begin with 0. Port numbering depends on the number of interfaces on the
NetEngine 8000 F2A-8K36H.
