● On a cabinet at the middle of a row, there are four points for cabinet combination at
both the front door and rear door.
● On a cabinet at the end of a row, there are two points for cabinet combination at both
the front door and rear door.
● The height
dierence and distance between cabinets cannot exceed 3 mm after
cabinets are combined.
----End
Securing the Cabinet
Procedure
Step 1 Verify that the spring washers, at washers, and installation covering have been
correctly installed on the expansion bolts.
Step 2 Secure expansion bolts on diagonal lines using a torque socket, with a torque of
45 N•m. See Figure 4-229.
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 569
