Electrostatic discharge is hazardous to the electronic equipment. Wear an ESD
wrist strap and ensure that the strap is grounded properly before touching the
equipment and boards, to protect the static-sensitive components against
electrostatic discharge of the human body. Otherwise, the equipment may be
damaged or the service may be interrupted.
Procedure
1. Shut down the laser and disconnect the ber end before inspecting the ber
connector.
2. Test the optical power using a power meter to ensure that the laser is shut
down.
3. Press down and hold the lever of the cassette cleaner. The shutter slides back
and exposes a new cleaning area. See Figure 4-244.
Figure 4-244 Using the cassette cleaner
4. Place the ber end face gently against the cleaning area.
5. Drag the ber end face gently on one cleaning area in the arrow direction
each time. See Figure 4-245. Do it again on the other cleaning area in the
same direction as the
rst time once. See Figure 4-246.
Do not drag the ber end face on the same cleaning area more than once.
Otherwise, the connector can be contaminated or damaged.
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 595
