Huawei Quidway S3100 Series User Manual

Operation Manual – Login
Quidway S3100 Series Ethernet Switches Chapter 2 Logging in through the Console Port
Huawei Technologies Proprietary
2-8
z The history command buffer can contain up to 20 commands.
z The timeout time of the AUX user interface is 6 minutes.
II. Network diagram
User PC running Telnet
Ethernet1/0/1
Ethernet
User PC running Telnet
Ethernet1/0/1
Ethernet
Figure 2-5 Network diagram for AUX user interface configuration (with the
authentication mode
being none)
III. Configuration procedure
# Enter system view.
<Quidway> system-view
# Enter AUX user interface view.
[Quidway] user-interface aux 0
# Specify not to authenticate users logging in through the Console port.
[Quidway-ui-aux0] authentication-mode none
# Specify commands of level 2 are available to users logging into the AUX user
interface.
[Quidway-ui-aux0] user privilege level 2
# Set the baud rate of the Console port to 19,200 bps.
[Quidway-ui-aux0] speed 19200
# Set the maximum number of lines the screen can contain to 30.
[Quidway-ui-aux0] screen-length 30
# Set the maximum number of commands the history command buffer can store to 20.
[Quidway-ui-aux0] history-command max-size 20
# Set the timeout time of the AUX user interface to 6 minutes.
[Quidway-ui-aux0] idle-timeout 6
