Operation Manual – SNMP

Quidway S3100 Series Ethernet Switches Chapter 1

SNMP Configuration

Huawei Technologies Proprietary

1-3

Table 1-1 Common MIBs

MIB attribute MIB content References

MIB II based on TCP/IP

network device

RFC1213

RFC1493

BRIDGE MIB

RFC2675

RIP MIB RFC1724

RMON MIB RFC2819

Ethernet MIB RFC2665

OSPF MIB RFC1253

Public MIB

IF MIB RFC1573

DHCP MIB

QACL MIB

ADBM MIB

IGMP Snooping MIB

RSTP MIB

VLAN MIB

Device management

Interface management

—

QACL MIB —

ADBM MIB —

RSTP MIB —

VLAN MIB —

Device management —

Private MIB

Interface management —

1.2 Configuring SNMP Basic Functions
