Huawei Quidway S3100 Series User Manual

Operation Manual – Login
Quidway S3100 Series Ethernet Switches Chapter 3 Logging in through Telnet
Huawei Technologies Proprietary
3-8
Table 3-7 Determine the command level when users logging into switches are
authenticated in the password mode
Scenario
Authentication mode User type Command
Command
level
The user privilege
level level command
not executed
Level 0
Password
(authentication-mode
password)
VTY users
The user privilege
level level command
already executed
Determined
by the level
argument
3.3.2 Configuration Example
I. Network requirements
Assume that you are a level 3 AUX user and want to perform the following configuration
for Telnet users logging into VTY 0:
z Authenticate users logging into VTY 0 using the local password.
z Set the local password to 123456 (in plain text).
z Commands of level 2 are available to users logging into VTY 0.
z Telnet protocol is supported.
z The screen can contain up to 30 lines.
z The history command buffer can contain up to 20 commands.
z The timeout time of VTY 0 is 6 minutes.
II. Network diagram
Console port
Console cable
RS-232
Console port
Console cable
RS-232
Figure 3-2 Network diagram for Telnet configuration (with the authentication mode
being passw
ord)
III. Configuration procedure
# Enter system view.
<Quidway> system-view
