Table 1-8 ICMP message types
Name ICMP TYPE ICMP CODE
echo Type=8 Code=0
echo-reply Type=0 Code=0
fragmentneed-DFset Type=3 Code=4
host-redirect Type=5 Code=1
host-tos-redirect Type=5 Code=3
host-unreachable Type=3 Code=1
information-reply Type=16 Code=0
information-request Type=15 Code=0
net-redirect Type=5 Code=0
net-tos-redirect Type=5 Code=2
net-unreachable Type=3 Code=0
parameter-problem Type=12 Code=0
port-unreachable Type=3 Code=3
protocol-unreachable Type=3 Code=2
reassembly-timeout Type=11 Code=1
source-quench Type=4 Code=0
source-route-failed Type=3 Code=5
timestamp-reply Type=14 Code=0
timestamp-request Type=13 Code=0
ttl-exceeded Type=11 Code=0
1.5.4 Configuration Example
# Configure ACL 2000 to deny the packets with their source addresses being 1.1.1.1.
<Quidway> system-view
[Quidway] acl number 2000
[Quidway-acl-basic-2000] rule deny source 1.1.1.1 0
[Quidway-acl-basic-2000] display acl 2000
