Huawei Quidway S3100 Series User Manual

Operation Manual – Login
Quidway S3100 Series Ethernet Switches Chapter 2 Logging in through the Console Port
Huawei Technologies Proprietary
2-11
2.5.2 Configuration Example
I. Network requirements
Assume that you are a level 3 VTY user and want to perform the following configuration
for users logging in through the Console port:
z Authenticate users logging in through the Console port using the local password.
z Set the local password to 123456 (in plain text).
z The commands of level 2 are available to users logging into the AUX user
interface.
z The baud rate of the Console port is 19,200 bps.
z The screen can contain up to 30 lines.
z The history command buffer can store up to 20 commands.
z The timeout time of the AUX user interface is 6 minutes.
II. Network diagram
User PC runnin
g
Telnet
Ethernet1/0/1
Ethernet
User PC runnin
g
Telnet
Ethernet1/0/1
Ethernet
Figure 2-6 Network diagram for AUX user interface configuration (with the
authentication mode being
password)
III. Configuration procedure
# Enter system view.
<Quidway> system-view
# Enter AUX user interface view.
[Quidway] user-interface aux 0
# Specify to authenticate users logging in through the Console port using the local
password.
[Quidway-ui-aux0] authentication-mode password
# Set the local password to 123456 (in plain text).
