Operation Manual – Login
Quidway S3100 Series Ethernet Switches Chapter 7 Controlling Login Users
Huawei Technologies Proprietary
7-8
II. Network diagram
InternetInternet
Sw itc hSw itc h
s
Figure 7-3 Network diagram for controlling Web users using ACL
III. Configuration procedure
# Define a basic ACL.
<Quidway> system-view
[Quidway] acl number 2030 match-order config
[Quidway-acl-basic-2030] rule 1 permit source 10.110.100.46 0
[Quidway-acl-basic-2030] rule 2 deny source any
# Apply the ACL to only permit the Web users sourced from the IP address of
10.110.100.46 to access the switch.
[Quidway] ip http acl 2030
