Huawei WIFI AX2 User Manual

The wireless network adapter can then automatically obtain an IP
address.
You can also manually set the IP address of the computer. Select TCP/IP
and select Manually from the
Congure IPv4 drop-down list. Set IPv4
Address to a static IP address "192.168.3.*" (* is an integer ranging from
2 to 254) that is in the same network segment as the router, set Router
to "192.168.3.1", and click OK.
NO TE
Generally, the address of the web-based management page is on the nameplate
at the bottom of the router for the default IP address. However, the address may
vary for the carrier custom versions. Use the actual address printed on the
nameplate on the bottom of the router or consult the carrier.
HUAWEI_WIFI_AX2
HUAWEI_WIFI_AX2
28 How do I access the web-based management
page of my router on an Apple computer
Issue 01 (2022-02-18) Copyright © Huawei Technologies Co., Ltd. 108

Huawei WIFI AX2 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	1201 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Antennas quantity	4
Internal memory	128 MB
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Output current	1 A
Power source type	AC, DC
Power consumption (typical)	12 W
Security algorithms	SSID, WPA3
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product type	Tabletop router
Product color	White
Ethernet LAN (RJ-45) ports	3
Mobile network generation	-

Weight and Dimensions

Depth	163.5 mm
Width	257.6 mm
Height	29 mm
Weight	216 g
