Huawei WIFI AX2 User Manual

23 How do I export my HUAWEI
router's conguration le
Step 1 Connect your computer to the router's Wi-Fi network (or connect the computer to
the router's LAN port using an Ethernet cable). In the browser address bar, enter
the default IP address and log in to the router's web-based management
page(check the nameplate at the bottom of the router for the default IP address).
NO TE
For routers that feature self-adaptive ports, you do not need to distinguish between WAN
and LAN ports.
Step 2 Go to More Functions > System Settings > Backup & Restore. Click Export
Conguration to save the .conf conguration le to your computer.
HUAWEI_WIFI_AX2
HUAWEI_WIFI_AX2
23 How do I export my HUAWEI router's
conguration le
Issue 01 (2022-02-18) Copyright © Huawei Technologies Co., Ltd. 78

Huawei WIFI AX2 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	1201 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Antennas quantity	4
Internal memory	128 MB
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Output current	1 A
Power source type	AC, DC
Power consumption (typical)	12 W
Security algorithms	SSID, WPA3
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product type	Tabletop router
Product color	White
Ethernet LAN (RJ-45) ports	3
Mobile network generation	-

Weight and Dimensions

Depth	163.5 mm
Width	257.6 mm
Height	29 mm
Weight	216 g
