Digital Inputs 179
User Guide v 1.0 — February 2020 System Options
Table 13-3 describes the input signals on the Heats Page 1 screen.
Figure 13-1 Digital Inputs Screen (Heats Page 1)
Table 13-3 Heats Input Signals (Heats Page 1)
Signal Description
Remote Standby Puts all zones that have a Remote Standby setpoint into Standby mode
(Lower setpoint) when this input signal is activated.
Remote Boost Puts all zones that have a Remote Boost setpoint into the Boost mode
(Higher setpoint) when this input signal is activated.
Remote Start Puts the system in Start mode when this signal is remotely activated. This
stays in the state until the STOP key is selected or Remote Stop is
activated.
Remote Stop Puts the system in Stop mode when this signal is remotely activated. This
stays in the state until the START key is selected or Remote Start is
activated.
NOTE: The system cannot be started when this input is active
Manual Boost Puts all zones that have a Manual Boost setpoint set into Boost mode
(Higher setpoint) when this input signal is activated.
NOTE: This is the same as if an operator touched the boost key in the
operator interface.
Cooling Lines Not
Enabled
Shows the warning message 'Mold Cooling Lines are not Enabled' on the
screen until the signal has been deactivated. This signal should come
from a thermolator.
NOTE: If the thermolator is switched off (input signal active), the
warning message is shown.
To Next Page
