v 1.0 — February 2020 Altanium Matrix5
216 Install the Remote Operator Interface
Figure 15-24 Remote Operator Interface Mounting Holes
Figure 15-25 Remote Operator Interface Rubber Leveling Pads
WARNING!
Electrical and mechanical hazard- risk of death, serious injury and/or damage to the
equipment. Turn off all power to the system and disconnect it completely from the
main input power.
