ContaminationSensor
Permissible viscosity range 10 … 350 mm²/s / 46 … 1622 Sus
(for hydraulic oil up to ISO VG 68)
Maximal suction height 1 m
Suction hose DN4 open-end, color: clear-transparent,
Length = 0.3 m
High-pressure hose DN4 with screw connection for measurement
point 1620,
color: black, Length = 2 m
Return hose DN7 open-end, color: clear-transparent,
Length = 1 m
Electrical data
Supply voltage 24 V DC, ± 20%, residual ripple ≤ 10%
Power consumption 100 W maximum
Current consumption 4 A maximum
Type of operation S3, periodic intermittent duty as per
DIN EN 60034-1 / DIN VDE 0530 part 1
relating to a useful life of 10 minutes.
Relative duty cycle 40 %
IP class IP 50 (open, in operation)
IP 67 (closed)
Protection class III (low voltage protection)
General data
Seal material FKM (FPM, Viton
®
)
Permitted temperature
range of fluid
0 … 70 °C / 32 … 158 °F
Permissible ambient
temperature range
0 … 45 °C / 32° … 113 °F
Permitted storage
temperature range
-40 … 80 °C / -40 … 176 °F
Permitted relative humidity max. 90%, non-condensing
Weight when empty ≈ 13 kg
FCU1310
