Hydac FCU 1310 - Technical Data

Technical Data
Technical Data
ContaminationSensor
Self diagnostics continuously with error indication
via status LED and display
Display LED, 6 / 4 / 4-digit, each with 17 segments
Measured values for solid
particle contamination
ISO code / SAE class / NAS class
Measured values for fluid
temperature
-25 … 100 °C / -13 … 212 °F
Measured values for water
saturation
0 … 100 %
Measuring range Display of ISO code between:
9/8/7 - 25/24/23.
Calibrated within the range of ISO code:
13/11/10 - 23/21/18
Accuracy CS: ± ½ ISO code
AS: ≤ ±3% over the entire measurement
range
Service Display /
Measuring time configurable 10 … 300 Seconds
Hydraulic data
Suitable Fluids Mineral oil or raffinate based on mineral oil
Hydraulic connections
Test connector type 1604
DN7 nipple socket
Maximum permissible
operating pressure at
connection
without high-pressure
adapter
-0.5 … 45 bar / 0 … 650 psi
With high-pressure adapter 15 … 345 bar / 217 … 5000 psi
Maximum permissible
operating pressure at
connection
0 … 0.5 bar / 0 … 7.5 psi
Measurement flow rate 30 - 500 ml/min (viscosity dependent)
FCU1310
en(us)
Page 108 / 124
BeWa FCU1310 V300 3371346f en-us 2017-01-27.docx 2017-01-27
