Preparing the FCU for measurement
Measuring up to max. 45 bar / 650 psi
WARNING
Hydraulic systems are under pressure
Danger of bodily injury
► The system must be depressurized before
performing any work on the product.
► If the pressurized connection is connected to
the hydraulic system, oil will flow through the
FCU.
► Make sure that the specified sequence is
followed.
NOTICE
If the operating pressure exceeds 45 bar / 650 psi
The excess pressure will be discharged via port OUTLET
► Never seal the connection OUTLET.
► Put the free end of the OUTLET return hose into an unpressurized
container.
► When operating, always observe the permissible operating pressure.
The FCU can withstand pressures up to 345 bar / 5000 psi.
