Preparing the FCU for measurement
Required hoses:
-
Return hose
-
High-pressure hose
Make sure that the following sequence is observed:
1.
Go through the steps in chapter
"FCU für die Messung vorbereiten“
on pages 36 to 39.
2.
Check the pressure at the
measurement location. The pressure
there must be in the range of
1 to 45 bar / 14 to 650 psi.
If the pressure exceeds
45 bar / 650 psi, use the high-
pressure adapter (see page 43).
