The integrated AquaSensor continuously
measures the fluid temperature. The
output as Celsius °C or Fahrenheit °F can
be selected under TP.UNIT on page 65.
Example: Temperature = 37.8 °C
Display service variables
These values give you information about the determined flow and the light
source power. The service variables are not calibrated.
" " service variable
Here, you can see the averaged flow
through the ContaminationSensor unit.
Example: Flow rate = 120 ml/min
" " service variable
Display of the light source efficiency (1-
100%) with which the
ContaminationSensor currently works.
Example: Light source efficiency = 60%
FCU1310
en(us)
Page 54 / 124
BeWa FCU1310 V300 3371346f en-us 2017-01-27.docx 2017-01-27
