Performing measurements
Check all the hydraulic and electrical connections to the FCU.
Now press the green "Pump ON" switch.
The pump feeds oil to be analyzed through the FCU
After the set measurement duration, the result will be shown on the
display, and the status LED will light up green, steadily.
NOTICE
Impermissible operating conditions
The FCU will be destroyed
► Use the FCU with mineral oils or mineral oil-based raffinates whose
flash point is higher than 55°C / 131°F.
► Observe the permissible viscosity range (up to ISO VG 68):
10 - 350 mm²/s / 46 - 1622 SUS.
► Only operate the FCU in periodic intermittent duty (S3) with a relative
duty cycle of 40% in relation to a useful life of 10 minutes.
(S3 according to DIN EN 60034 / VDE 0530).
► Never use the FCU without a suction screen.
