Hypertherm HyPerformance Plasma HPR400 User Manual

Appendix B – CnC interfACe protoCol
b-18 HPR400XD Auto Gas – 806160
ID Command System Description
126 GET_INFO2 Auto gas control
board only
See 079
127 GET_INFO3 Auto gas control
board only
See 079
131 CLEAR WARNINGS Manual gas system
Auto gas system
This command will clear error codes less than #43.
Sample:
>13195<
>1311C6<
132 READ COOLANT PRESSURE HPR260 ONLY This command returns the raw A/D value for coolant pressure.
83 counts = 225 psi
73 counts = 200 psi
Sample:
>13296<
>13280FE<
133 GET CONTROL DATA3 HPR400XD ONLY This command provides data for the 3rd and 4th choppers used in
the HPR400 system.
Chopper C temp (raw A/D)
Chopper D temp (raw A/D)
Chopper C current (amps)
Chopper D current (amps)
Data:
None
Return value:
Above info space-delimited.
Sample:
>13397<
>133CCT0482 CDT0021 CCC0000 CDC000050<
134 READ ERROR LOG ALL HPR SYSTEMS This command will return the last 4 error codes the system
encountered. The log will only record errors (error code values
greater than 0). It ignores error code 0, which indicates no error
orthat an error has been cleared.
The error codes are listed space-delimited, most recent error first.
Data:
None
Return value:
Error – most recent (see table IV Error Codes)
Error #2
Error #3
Error – oldest error
Sample:
>13498<
>134020 020 024 0534A<
Command table (13 of 14)

Hypertherm HyPerformance Plasma HPR400 Specifications

General

Duty Cycle	100% at 400 A
Cutting Capacity	up to 50 mm (2 in)
Output Current	30-400 A
Input Voltage	200 – 480 V, 3-PH, 50/60 Hz
Gas Supply	Oxygen, Air, Nitrogen
