23
4.2 External Drive-Power Cutoff Relay Type (RCP2-CG)
4.2.1 Configuration
PERSONAL
COMPUTER
S1
S2
MPI
MPO
24V
N
EMG
Safety relay
contactor for
motor drive-
power cutoff
circuit
Standard teaching pendant
<RCA-T>
Optional
Cable length: 5 m
External unit
<RCB-105-2> Cable length: 2 m
<RCB-105-5> Cable length: 5 m
Optional
PC
PC software
<RCB-101-MW>
Optional
Input power supply
24 VDC 24V
0
FG
Host system <PLC>
Supplied flat
cable
Cable length: 2 m
Robo cylinder
Cable length: 5 m
Optional
