Hard disk drive cable connection
The following illustration shows the internal routing and connectors for the two SAS
signal cables.
SAS signal cables
Port 0-3
Port 4-5
Port 0-3
Port 4-5
204 IBM System x3650 M4 Type 7915: Problem Determination and Service Guide
