Screw
Safety cover
6. Remove the screw from the safety cover.
7. Disconnect the hard disk drive backplane power cables from the connector in
front of the safety cover.
8. Slide the cover forward to disengage it from the system board, and then lift it
out of the server.
9. If you are instructed to return the 240 VA safety cover, follow all packaging
instructions, and use any packaging materials for shipping that are supplied to
you.
Installing the 240 VA safety cover
To install the 240 VA safety cover, complete the following steps.
Screw
Safety cover
212 IBM System x3650 M4 Type 7915: Problem Determination and Service Guide
