System-board external connectors
The following illustration shows the external input/output connectors on the system
board.
Dedicated
systems-
management
Ethernet
connector
Video
connector
Serial
connector
USB 3 - 6
connectors
Ethernet 2
connector
Ethernet 1
connector
Ethernet 4
connector
Ethernet 3
connector
