4. Reconnect the internal cables that you disconnected (see “Internal cable routing
and connectors” on page 194).
5. Install the cover (see “Installing the cover” on page 206).
6. Slide the server into the rack.
7. Reconnect the external cables; then, reconnect the power cords and turn on the
peripheral devices and the server.
Note: You must wait approximately 2.5 minutes after you connect the power
cord of the server to an electrical outlet before the power-control button
becomes active.
8. Start the Setup utility and reset the configuration.
v Set the system date and time.
v Set the power-on password.
v Reconfigure the server.
See Chapter 6, “Configuration information and instructions,” on page 297 for
details.
Removing the operator information panel assembly
To remove the operator information panel assembly, complete the following steps.
Operator information
panel
1. Read the safety information that begins on page vii and “Installation guidelines”
on page 191.
2. Turn off the server and peripheral devices and disconnect all power cords.
3. Remove the cover (see “Removing the cover” on page 205).
4. Disconnect the cable from the back of the operator information panel assembly.
5. Reach inside the server and press the release tab; then, while you hold the
release tab down, push the assembly toward the front of the server.
6. From the front of the server, carefully pull the operator information panel
assembly out of the server.
Chapter 5. Removing and replacing server components 277
